High Precision Tungsten Steel Carbide Tube Metal Lathe Cutting Tools For Milling

Large Image : High Precision Tungsten Steel Carbide Tube Metal Lathe Cutting Tools For Milling

Product Details:

Place of Origin:	Dongguan, China
Brand Name:	HIPPSC
Certification:	ISO9001
Model Number:	HWS08-M04-75

Payment & Shipping Terms:

Minimum Order Quantity:	1-5 pcs
Price:	Negotiable (Price term: EXW, FOB, CFR, CIF )
Packaging Details:	Plastic Box with Inner PE Bag In Carton
Delivery Time:	2~30 Work days
Payment Terms:	T/T, Western Union, Paypal, L/C
Supply Ability:	5000 pcs Per Month

Contact Now

Detailed Product Description

Spindle Type:	HWS-M	Color:	Siliver White
Clamp Dia:	M6~M16	Runout:	0.003mm
Material:	Special Steel	Machining:	Finishing Maching And Deep Hole Processing
Highlight:	cemented carbide rods , tungsten carbide round bar

High Precision Tungsten Steel Carbide Tube Metal Lathe Cutting Tools For Millling

Ⅰ. Features And Advantages

1 Reduce interference well,

2 High rigidity, good shock resistance.

3 Made from fully tungsten steel.

4 Suits abundant indexable boring bar/head.

5 Easy to operate and change tool quickly.

6 Super precision even for deep hole machining.

Ⅱ. Technical Parametes

Product Name	Tungsten Carbide Tube
Spindle Type	HWS-M
Clamping Range	M6~M16
Runout	<0.003mm
Processing Type	Deep Hole Finishing Machining.
Product Material	Special steel
Hardness	HRC48~52°

Ⅲ. Product Introduction
High Precision Tungsten Steel Carbide Tube Metal Lathe Cutting Tools For Milling

Standard Items

HWSat.No	L	D3	D2	D1	M
HWS08-M04-75	75	2	4.5	8	M04
HWS08-M04-100	100	2	4.5	8	M04
HWS10-M05-75	75	3	5.5	10	M05
HWS10-M05-100	100	3	5.5	10	M05
HWS10-M05-125	125	3	5.5	10	M05
HWS10-M05-150	150	3	5.5	10	M05
HWS10-M06-75	75	3	6.5	10	M06
HWS10-M06-100	100	3	6.5	10	M06
HWS10-M06-125	125	3	6.5	10	M06
HWS10-M06-150	150	3	6.5	10	M06
HWS12-M06-75	75	3	6.5	12	M06
HWS12-M06-100	100	3	6.5	12	M06
HWS12-M06-125	125	3	6.5	12	M06
HWS12-M06-150	150	3	6.5	12	M06
HWS16-M08-100	100	4	8.5	16	M08
HWS16-M08-150	150	4	8.5	16	M08
HWS16-M08-200	200	4	8.5	16	M08
HWS20-M10-150	150	4	10.5	20	M10
HWS20-M10-200	200	4	10.5	20	M10
HWS20-M10-250	250	4	10.5	20	M10
HWS25-M12-150	150	6	12.5	25	M12
HWS25-M12-200	200	6	12.5	25	M12
HWS25-M12-250	250	6	12.5	25	M12
HWS25-M12-300	300	6	12.5	25	M12
HWS32-M16-200	200	8	17	32	M16
HWS32-M16-250	250	8	17	32	M16
HWS32-M16-300	300	8	17	32	M16
HWS32-M16-350	350	8	17	32	M16
HWS32-M16-400	400	8	17	32	M16

High Precision Tungsten Steel Carbide Tube Metal Lathe Cutting Tools For Milling

Heat Shrinking Machine

Ⅳ. Overview for HIPPSC Products

BT40 90mm Clamping Heat Shrinking Tool Holders.
Threaded/Screw-on/Thread Screw Tool Holders.
Tool Holders/Arbors/Shanks for Mirror Finishing.
Torque Floating Tap/Tapping Chuck and Collet.
ER/SK/Hydraulic/Back lock/Floating tapping Collet
High Speed ER/SK/GER/GSK Tool Holder for CNC Working.

Ⅴ. Shipment

By Sea; By Air; By Train/Truck.

TNT, EMS, DHL, UPS, FedEx.

Ⅵ. Packing

PE Bag.
Plastic Box
Carton Box.

Other Materials

Rust Presensitive Oil.
Adhesive Tape.
Packing Belt.

Ⅶ. Warehouse

1.   Sufficient Inventory For All Standard Products to Guarantee On-time Delivery.
2.   All Materials and Products Must Be Inspected and Checked Strictly and Carefully
      By IQC and OQC Operater Before Being Shipped Out.
3.   Using Special Equipment and Gauge To Check Technical Parameters.
High Precision Tungsten Steel Carbide Tube Metal Lathe Cutting Tools For Milling

Ⅷ. Manufacturing and Sales Service

1.   Manufacturing with Professional and Precise Equipments Under Experienced Workers.
2.   OEM and ODM Service Are All Available Here, Produce To Customer's Need/Requirement.
3.   Professional Serving Team Provides One-Stop Considerate and Satisfying Service To You.
